Rear Motorized Horizontal Split Velvet Stage Traveler Curtain System

Product Overview

The Rear Motorized Horizontal Split Velvet Stage Traveler Curtain System is a professionally engineered stage curtain solution designed for auditoriums, theatres, performing arts centres, convention halls, educational institutions, and multipurpose venues. Installed behind the main stage curtain, the system provides smooth, synchronized, and reliable curtain movement through a precision-engineered motorized track mechanism, enabling efficient stage masking, scene transitions, and backstage concealment.

Manufactured using premium 450 GSM Molfino velvet fabric and a heavy-duty motorized drive system, the curtain delivers exceptional durability, luxurious aesthetics, and enhanced acoustical performance. The system is designed for silent operation, precise control, and long-term reliability, making it ideal for professional stage environments.

Purpose of the System

The primary purpose of a rear stage traveler curtain is to divide, conceal, and organize backstage areas while providing flexibility for stage productions, theatrical performances, conferences, cultural programs, and live events. It allows operators to create multiple stage configurations, hide equipment and performers from audience view, and manage scene changes efficiently.

The system improves stage functionality, enhances production quality, and contributes to a professional auditorium experience.

Why Use a Rear Motorized Stage Traveler Curtain?

Conceals backstage areas, equipment, and performers
Supports seamless scene transitions during performances
Creates flexible stage layouts and stage divisions
Enhances stage aesthetics and audience experience
Provides smooth and effortless motorized operation
Eliminates manual curtain handling
Improves operational safety through automatic stop mechanisms
Enables operation from both stage and control room locations
Enhances auditorium acoustics through heavy velvet fabric
Delivers long service life with minimal maintenance

Key Features

Motorized Horizontal Split Curtain Operation
Heavy-Duty Modular Curtain Track System
Precision Engineered Gearbox Drive
Smooth and Silent Curtain Movement
Variable Speed Control
Programmable Acceleration & Deceleration
Dual Operation (Motorized & Manual)
Automatic Limit Stop Mechanism
Premium 450 GSM Velvet Fabric
Flame Retardant Treatment Option
Stage and Control Room Operation
Optional Wireless Remote Control
Heavy-Duty Structural Support Framework
Professional Installation & Commissioning

Applications

Auditoriums
Theatres
Performing Arts Centres
School & College Auditoriums
Convention Centres
Cultural Centres
Multipurpose Halls
Community Centres
Government Auditoriums
Corporate Event Venues

Technical Specifications

Curtain Type - Rear Motorized Horizontal Split Traveler Curtain
Curtain Fabric - Premium Polyester Molfino Velvet
Fabric Weight - 450 GSM
Operation Type - Fully Motorized with Manual Override
Motor Capacity - 1 HP
Motor Make - Godrej / Crompton Greaves
Drive System - Engineered Modified Gearbox
Track System - Heavy-Duty Modular Steel Track
Control System - Push Button Control Panel
Control Location - Stage & Control Room
Safety Features - Automatic Limit Stop Mechanism
Wire Rope - 3 mm Steel Wire Rope
Structural Support - Ladder Type MS Frame
Finish - Matte Black
Optional Feature - Wireless Remote Control
Flame Retardant Treatment - Available
Fabric Approval - As Approved by EIC / End User
Fabrication Material - TATA / JINDAL / APOLLO / KAMDHANU
Installation By - Stage Works

Scope of Supply

The system includes complete supply, fabrication, installation, testing, commissioning, curtain track assembly, motorized drive mechanism, gearbox, runners, rollers, pulleys, clamps, wire rope system, structural supports, electrical control panel, safety devices, mounting accessories, curtain fabrication, onsite installation, and all necessary hardware required for successful operation.

The complete installation is carried out by experienced stage engineering professionals under approved project drawings and technical supervision to ensure smooth performance, safety, and long-term reliability.
