Stage Cyclorama High Gain Matt White Projector Screen

Product Overview

The Stage Cyclorama High Gain Matt White Projector Screen is a premium stage backdrop solution designed for auditoriums, theatres, multipurpose halls, performing arts centres, and venues requiring versatile visual effects. The system provides a smooth, continuous surface that enhances lighting and projection capabilities, enabling customized themes through colour washes, pattern projections, and special effects. Manufactured with a structural MS triangular truss frame (25–32 mm die fix frame) overlapped with 1.8 Power High Gain Matt White fabric featuring seamless joints every 72 inches, the screen delivers excellent opacity, light diffusion, and high-definition projection quality. Designed for DLP and LCD cinema projectors, the system supports low contrast ratio projectors with high-definition video sources, creating immersive audience experiences while ensuring structural strength, corrosion resistance, and long-term durability.

Purpose of the System

The primary purpose of a stage cyclorama screen is to provide a versatile backdrop that can be transformed with lighting, projections, and special effects to create thematic environments for performances, events, presentations, and cinematic screenings. It serves as a foundational visual element during theatrical productions, concerts, conferences, cultural events, and film screenings. The system enhances stage aesthetics, improves light reflection and diffusion, enables infinite pattern and depth effects via moving heads and cyclorama lights, and creates a professional, immersive experience for audiences.

Why Choose This System?

Provides a smooth, continuous surface for superior lighting and projection effects
Enables customized themes via colour washes, patterns, and special effects
Delivers high-gain projection with 1.8 Power Matt White fabric
Supports DLP and LCD cinema projectors with high-definition video sources
Offers excellent opacity and light diffusion for clear visuals
Features seamless joints every 72 inches for uninterrupted display
Constructed with triangular truss MS frame for extreme strength and durability
Contains high manganese content for controlled grain structure and stronger design
Artificially aged for enhanced corrosion resistance
Provides safer stage and working environment
Allows colour washing from top cyclorama lights and pattern projection from moving heads
Includes 4-inch black masking studs on all sides for clean projection edges
Features washable screen surface with mild soap and water
Custom sizes to fit any stage setup
Onsite fabrication as per architectural drawings and EIC instructions

Key Features

High Gain Matt White Projection Surface (1.8 Power)
Seamless Joint Every 72 Inches
4-Inch Black Masking Studs on All Sides
Triangular Truss Cyclorama Frame (Onsite Fabricated)
Structural MS Frame as per Detailed Drawings
25–32 mm Die Fix Frame (Tubular MS Pipe)
Fixing from Floor, Rear Wall & Ceiling with Fasteners
High Manganese Content for Grain Structure Control
Artificially Aged for Corrosion Resistance
Compatible with DLP & LCD Cinema Projectors
Optimized for Low Contrast Ratio Projectors with HD Video Source
Washable Screen Surface (Mild Soap & Water)
Supports Cyclorama Lights (Top Colour Wash)
Supports Moving Heads on Intelligent Bar for Infinite Pattern & Depth
Onsite Fabrication & Installation
Execution as per Architectural Drawings & EIC Instructions

Applications

Auditoriums
Theatres
Multipurpose Halls
Performing Arts Centres
Film Screening Venues
Concert Stages
Conference Centres
Cultural Centres
Corporate Event Spaces
Television Studios
School & College Auditoriums
Houses of Worship

Technical Specifications

System Type - Stage Cyclorama High Gain Matt White Projector Screen
Screen Fabric - High Gain Matt White Projector Screen Fabric
Fabric Gain - 1.8 Power
Fabric Opacity - Excellent
Light Diffusion - High
Seam Type - Seamless Joint Every 72 Inches
Black Masking - 4-Inch Black Masking Studs on All Sides
Projector Compatibility - DLP & LCD Cinema Projectors
Video Source Compatibility - High-Definition (Low Contrast Ratio Projectors)
Screen Surface - Washable with Mild Soap & Water
Frame Type - Triangular Truss Cyclorama Frame (Onsite Fabricated)
Frame Material - Structural MS Pipe (25 mm to 32 mm Die Fix Frame)
MS Structure Make - TATA / JINDAL / KAMDHENU / APOLLO
Screen Make - PRIMA / CINEMA WORKS / LIBERTY
Frame Fixing - Floor, Rear Wall & Ceiling with Fasteners
Structural Design - High Manganese Content for Grain Structure Control, Artificially Aged for Corrosion Resistance
Strength Feature - Extreme Strength, Superior Durability, Safer Working Environment
Lighting Integration - Cyclorama Lights (Top Colour Wash) + Moving Heads on First Intelligent Bar (Pattern & Depth)
Customization - Custom Sizes to Fit Any Stage Setup
Compliance - As per Architectural Drawings & Engineer-in-charge (EIC) Instructions
Inclusions - All Tools, Tackles, Machineries, Manpower, Staging, Consumables, etc. Complete

Scope of Supply

The system includes complete supply, onsite fabrication, installation, testing, and commissioning of the Stage Cyclorama High Gain Matt White Projector Screen, comprising triangular truss MS frame onsite manufactured as per architectural drawings, structural MS pipe frame made from 25–32 mm die fix frame, high gain matt white projector screen fabric overlapped on frame with seamless joints every 72 inches, 4-inch black masking studs on all sides, fixing from floor, rear wall and ceiling with heavy-duty fasteners, all structural steel from TATA/JINDAL/KAMDHENU/APOLLO, screen fabric from PRIMA/CINEMA WORKS/LIBERTY, and all necessary hardware, tools, tackles, machineries, manpower, staging, consumables, and accessories required for successful operation. The complete installation is carried out by experienced stage engineering professionals under approved project drawings, architectural specifications, and technical supervision of the Engineer-in-charge (EIC) to ensure smooth surface alignment, optimal projection quality, structural integrity, corrosion resistance, and long-term reliability for professional stage visuals and immersive audience experiences.
