Motorized Horizontal Center Split Velvet Stage Traveler Curtain System

Product Introduction

The Motorized Horizontal Center Split Velvet Stage Traveler Curtain System is a premium stage engineering solution designed for auditoriums, theatres, convention centers, educational institutions, performing arts venues, and multipurpose halls. The system provides smooth, synchronized, and automated curtain movement, allowing professional opening and closing of the main stage curtain while enhancing the overall visual appeal of the performance area.

Designed with a precision-engineered track and drive mechanism, the system combines heavy-duty structural support, advanced motorized operation, and luxurious velvet curtain fabric to deliver reliable long-term performance. The center-split design allows the curtain to open equally from the center towards both sides, creating a dramatic stage reveal and improving audience engagement.

Purpose of the System

A motorized stage traveler curtain serves as the primary stage masking and presentation element. It is used to conceal the stage before performances, manage scene transitions, improve stage aesthetics, and create professional theatrical effects during events and performances.

The system helps operators control stage visibility effortlessly while maintaining a high level of safety, reliability, and operational efficiency.

Why Use a Motorized Stage Curtain?

Creates a professional auditorium and theatre environment.
Enhances stage presentation and audience experience.
Provides smooth and controlled curtain movement.
Eliminates manual pulling and operational effort.
Improves safety through automatic stop mechanisms.
Allows operation from both stage and control room.
Supports theatrical productions, conferences, ceremonies, and cultural events.
Adds luxury and elegance to the stage environment.
Helps improve auditorium acoustics through heavy velvet fabric.
Ensures long-term durability with industrial-grade components.

Key Technical Features

Motorized Horizontal Center Split Curtain Operation
Fully Automated Opening and Closing System
Precision Engineered Modular Curtain Track
Heavy-Duty Steel Rail & Track Assembly
Variable Speed Curtain Movement
Programmable Acceleration & Deceleration
Dual Operation Mode (Motorized + Manual Override)
Automatic Limit Stop Mechanism
Engineered Gearbox with Sealed Bearings
Self-Lubricating Roller & Runner System
Stage and Control Room Operation Facility
Heavy-Duty MS Support Structure
Flame Retardant Curtain Treatment
Optional Wireless Remote Control
Smooth, Silent & Vibration-Free Performance

Applications

Auditoriums
Theatres
School & College Halls
Convention Centres
Performing Arts Centres
Cultural Halls
Government Auditoriums
Corporate Event Spaces
Multipurpose Halls
Community Centres

Technical Specifications

Curtain Type: Motorized Horizontal Center Split Traveler Curtain

Curtain Fabric: Premium 100% Polyester Molfino Velvet

Fabric Weight: 450 GSM

Operation Type: Fully Motorized with Manual Override

Drive System: Engineered Gearbox Drive Mechanism

Motor Capacity: 1 HP (Godrej / Crompton Greaves)

Track System: Heavy Duty Modular Steel Curtain Track

Control System: Push Button Control Panel

Control Locations: Stage & Control Room

Safety Features: Auto Stop Micro Switches & Limit Mechanism

Wire Rope: 3 mm Steel Wire Rope

Structure Support: Ladder Type MS Frame Fixed on Mother Grid

Finish: Matte Black

Optional Feature: Wireless Remote Control

Flame Retardant Treatment: Available

Fabric Approval: As Approved by EIC / End User

Structural Material: TATA / JINDAL / APOLLO / KAMDHANU

Installation: Complete Supply, Installation, Testing & Commissioning

Mechanical Work & Installation: Stage Works India Pvt. Ltd.

Scope of Supply

The scope includes complete supply, fabrication, installation, testing, commissioning, structural supports, curtain tracks, motorized drive mechanism, gearbox assembly, control panel, rollers, runners, pulleys, wire rope system, electrical controls, mounting accessories, and all necessary hardware required for successful operation of the curtain system.
