LED Projector Ellipsoidal Profile 200W

Product Overview

The LED Projector Ellipsoidal Profile 200W is a professional auditorium stage lighting fixture designed for sharp beam control, performer highlighting, mood creation, and precise theatrical lighting effects. It is suitable for auditoriums, theatres, performing arts spaces, cultural stages, and multipurpose venues.

The fixture uses a 200W COB LED lamp with adjustable intensity, multiple colour temperature options, high CRI output, DMX control, and beam angle options for flexible stage lighting design. It is built with durable aluminum alloy housing and designed for high efficiency, long lifespan, low maintenance, and no UV output.

Purpose

The purpose of this ellipsoidal profile fixture is to provide controlled and focused stage illumination for performers, podiums, scenes, and performance areas. It helps create different moods, lighting effects, and stage atmospheres with accurate command-based control from the lighting console.

Key Features

• 200W LED ellipsoidal profile lighting fixture
• Suitable for auditorium and theatre stage lighting
• 200W COB LED lamp
• Adjustable intensity and colour temperature
• Colour options: WW / 3200K / 5600K / Two-colour / Full-colour RGBW
• High CRI Ra 90–97 for accurate colour rendering
• Beam angle options: 19° / 26° / 36° / 50°
• DMX512 compatible control system
• Control channel modes: 1CH / 2CH / 5CH
• Master/Slave and Auto Run operation
• Multiple lights can be connected in series
• Durable aluminum alloy body
• IP20 rated for indoor installation
• High efficiency, extended lifespan, and low maintenance
• No UV output
• Fully calibrated and ready for immediate use
• CE & RoHS certified
• Minimum three-year unconditional warranty

Technical Specifications

• Product Type - LED Projector Ellipsoidal Profile Light
• Power - 200W
• LED Source - 200W COB LED lamp
• Power Input - 260W
• Input Voltage - AC100–240V, 50/60Hz
• Product Size - 640mm x 350mm x 250mm
• Colour System - WW / 3200K / 5600K / Two-colour / Full-colour RGBW
• Colour Rendering Index - Ra 90–97
• Beam Angle - 19° / 26° / 36° / 50°
• Control Protocol - DMX512
• Control Channels - 1CH / 2CH / 5CH
• Operation Modes - DMX512 / Master-Slave / Auto Run
• Series Connection - Multiple fixtures can be connected in series
• Body Material - Aluminum alloy
• LED Lifespan - More than 50,000 hours
• Operating Temperature - -20°C to 40°C
• Protection Rating - IP20
• Performance - High efficiency, low maintenance, no UV output
• Certification - CE & RoHS
• Warranty - Minimum 3 years unconditional warranty
• Installation - As per Architectural Drawings and EIC instructions

Scope of Work

The scope includes supply, installation, laying, testing, commissioning, and programming of LED Projector Ellipsoidal Profile 200W fixtures for auditorium stage lighting applications.

The work includes fixture supply, placement drawing submission before commencement, installation as per approved drawings, DMX connection, addressing, programming, testing, focusing, calibration, commissioning, and final handover. The fixtures shall be delivered fully calibrated and ready for immediate use.

All required tools, machinery, manpower, staging, consumables, fixing accessories, and installation materials shall be included. The work shall be executed by a skilled and experienced team in strict accordance with Architectural Drawings and Engineer-in-Charge instructions.

Quality & Safety Requirements

• Fixtures shall comply with CE & RoHS certification standards
• Placement drawings shall be submitted before starting work
• DMX control, beam angle, colour temperature, and dimming shall be tested
• Fixtures shall respond accurately to lighting console commands
• Multiple fixture series connection shall be checked
• Lights shall be fully calibrated and ready for immediate use
• Installation shall follow approved drawings and EIC instructions
• Higher specifications may be accepted if they meet required standards
• Any deviation from specified standards shall not be accepted

Training & Warranty

Comprehensive onsite training shall be provided to the end user for fixture operation, DMX control, basic programming, focusing, safety handling, and maintenance.

All products shall be covered under a minimum three-year unconditional warranty to ensure long-term reliability and professional stage lighting performance.
